QX600™ & QX250i™
The SIM (Strobed Inspection Module) is at the core of every CyberOptics’ 2D AOI system. Designed and manufactured exclusively by CyberOptics, the SIM delivers high performance inspection at 110cm²/sec – And, it is absolutely calibration-free.
AI² (Autonomous Image Interpretation) technology in the QX250i ensures ultrafast programming and is capable of getting you from zero to production ready in less than 13 minutes*. Powered by an 80-megapixel sensor, QX250i™ significantly improves solder joint and 01005 inspection performance.
Overview
The QX Series 2D AOI Inspection Systems offer fast, flexible and high performance inspection for all applications. It is ideally suited for pre-reflow and Selection Inspection.
The top and bottom high-resolution Strobed Inspection Modules (SIMs) with enhanced illumination provide a single platform for the inspection and defect review process that shortens the production line and drives ~50% productivity improvement.
